Data sheet

Air purifier Bioxigen
Air purifier
  Cod. BXMCB2   Max capacity: ≤ 500 m3/h
Dimensions (Lx(P1+P2)xH) mm 260x(140+125)x210
Weight Kg 4,4
Power supply V/Ph/Hz 230/1/50-60
Consumption W 6
Condenser   2 x B

  Cod. BXMCC2   Max capacity : ≤ 1000 m3/h
Dimensions (Lx(P1+P2)xH) mm 260x(140+200)x210
Weight Kg 4,5
Power supply V/Ph/Hz 230/1/50-60
Consumption W 9
Condenser   2 x C

  Cod. BXMCC4AL   Max capacity : ≤ 2000 m3/h
Dimensions (Lx(P1+P2)xH) mm 310x(170+200)x230
Weight Kg 4,8
Power supply V/Ph/Hz 230/1/50-60
Consumption W 18
Condenser   4 x C

  Cod. BXMCC6AL   Max capacity : ≤ 3000 m3/h
Dimensions (Lx(P1+P2)xH) mm 310x(170+200)x230
Weight Kg 5,1
Power supply V/Ph/Hz 230/1/50-60
Consumption W 27
Condenser   6 x C
Catalog Manual
Air purifier Bioxigen
Air purifier
Cod. BXMCH4AL   Max capacity :  5000 m3/h
Dimensioni (Lx(P1+P2)xH) mm 310x(170+415)x230
Peso netto Kg 5,5
Alimentazione V/Ph/Hz 230/1/50-60
Consumo W 30
Condenser   4 x H

  Cod. BXMCH4AL   Max capacity : ≤ 7000 m3/h
Dimensions (Lx(P1+P2)xH) mm 310x(170+415)x230
Weight Kg 5,8
Power supply V/Ph/Hz 230/1/50-60
Consumption W 38
Condenser   6 x H
Catalog Manual
Air purifier Bioxigen
Air purifier Bioxigen
  Cod. BXMCB2   Max capacity : ≤ 25000 m3/h
Dimensions (Lx(P1+P2)xH) mm (2x) 295x783x(100+500)
Weight Kg 31
Power supply V/Ph/Hz 230/1/50-60
Consumption W (2x) 60
Condenser   12 x F

  Cod. BXMCF8L   Max capacity : ≤ 16000 m3/h
Dimensions (Lx(P1+P2)xH) mm 295x783x(100+500)
Weight Kg 16
Power supply V/Ph/Hz 230/1/50-60
Consumption W 80
Condenser   8 x F



Catalog Manual
